Especificaciones:

Hardware

Standard&Protocol

IEEE802.11a/b/g/n/ac/ax

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Ethernet Interface

3 x 10/100/1000Mbps RJ45 ports per node

Antenna

4 x 3dBi Internal antenna

Button

1 x Reset Button

1 x MESH Button

Power

Input: AC 100-240V, 50/60Hz

Output: DC 12 V ⎓ 1.5 A

Dimension

86x86x190mm (3.39 x3.39 x 7.48 in)

LED Indicator

1 x Tri-color LED Indicator(Green,Yellow,Red)

Wireless

Wireless Standard

IEEE802.11a/b/g/n/ac/ax

Wireless roaming

Comply with IEEE802.11k/v

Mesh network Standard

/

Rate

2.4GHz: 574Mbps (802.11ax)

5GHz: 2402Mbps (802.11ax)

Frequency

CE:

2.4G: 2412-2472MHz(CH1-CH13)

5G: 5150-5350MHz(CH36-CH64)

FCC:

2.4G: 2412-2462MHz(CH1-CH11)

5G: 5150-5350MHz(CH36-CH64)

5725-5850MHz(CH149-CH165)

Transmission Power

CE:

<20 dBm (2.4 GHz)

<23 dBm (5 GHz)

FCC:

<30 dBm (2.4 GHz)

<30 dBm (5 GHz)

Basic Features

Beam Forming

MU-MIMO

AP Steering

Band Steering

OFDMA

1024-QAM

Wireless Security

WPA3-SAE/WPA2-PSK

Software

Operating Mode

PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia)

Internet Connection Type

PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia)

DHCP Server

DHCP Server, DHCP Client List

Virtual Server

Port Forwarding, DMZ Host, UPnP

Parental Control

Client Filter

URL Filter

Time Limit

Firewall

Forbid TCP/UDP flood attack

VPN

PPTP Server, PPTP/L2TP Client

DNS

Support manually setting DNS server

Special Features

Ethernet Backhaul

IPv6

IPTV

Others

Support App and web management

Guest Network

Firmware upgrade online

Others

Operation Temperature

0 ~ 40 ℃

Storage Temperature

-40 ~ 70 ℃

Operating Humidity

10%~90% RH non-condensing

Storage Humidity

5%~90% RH non-condensing

APP installation

Available in iOS 9.0 or later, Android 4.4 or later

Certification

CE, FCC, RoHS

Package Contents

Mesh12X* 3, Power adapter x 3, QIG x 1, RJ45 Gigabit Ethernet cable x 1
