Specification

Camera

Image Sensor 1/2.9" Progressive Scan CMOS

Max. Resolution 1920 × 1080

Min. Illumination Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR

Shutter Time 1/3 s to 1/100,000 s

Day & Night IR cut filter

Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°

Lens

Lens Type Fixed focal lens, 2.8 and 4 mm optional

Focal Length & FOV 2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°

4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°

Lens Mount M12

Iris Type Fixed

Aperture F2.2

DORI

DORI 2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m

4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m

Illuminator

Supplement Light Type IR, White Light

Supplement Light Range IR: up to 20 m

White Light: up to 15 m

Smart Supplement Light Yes

IR Wavelength 850 nm

Video

Main Stream

50 Hz:25 fps (1920 × 1080, 1280 × 720)

60 Hz:30 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz:25 fps (640 × 480, 640 × 360)

60 Hz:30 fps (640 × 480, 640 × 360)

Video Compression Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

Video Bit Rate 32 Kbps to 8 Mbps

H.264 Type Baseline Profile, Main Profile, High Profile

H.265 Type Main Profile

Bit Rate Control CBR, VBR

Region of Interest (ROI) 1 fixed region for main stream

Audio

Audio Type Mono sound

Audio Bit Rate 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)

Environment Noise Filtering Yes

Audio Sampling Rate 8 kHz/16 kHz

Audio Compression G.711ulaw/AAC-LC

Network

Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP,NTP, IGMP, IPv4, IPv6, UDP, QoS

API Open Network Video Interface (Profile S, Profile T, Profile G (-F model supports Profile

G)), ISAPI, SDK

Security

Password protection, complicated password, watermark, basic and digest

authentication for HTTP, WSSE and digest authentication for Open Network Video

Interface, security audit log, host authentication (MAC address)

Simultaneous Live View Up to 6 channels

User/Host Up to 32 users

3 user levels: administrator, operator, and user

Client iVMS-4200, HiLookVision

Web Browser Plug-in required live view: IE 10, IE 11,

Local service: Chrome 80+, Firefox 80+, Edge 89+

Imágen

Wide Dynamic Range (WDR) Digital WDR

SNR ≥ 52 dB

Day/Night Switch Day, Night, Auto, Schedule

Image Enhancement BLC, HLC, 3D DNR

Image Settings Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client

software or web browser

Privacy Mask 1 programmable polygon privacy mask

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Built-in Microphone Yes, 1 built-in microphone

Reset Key -F model supports

Evento

Basic Event Motion detection (support alarm triggering by specified target types (human)),

exception

Linkage Upload to memory card (F model supports), send email, notify surveillance center,

trigger recording (F model supports), trigger capture

General

Power 12 VDC ± 25%, 0.45 A, max. 5.4 W, Ø 5.5 mm coaxial power plug, reverse polarity

protection,

PoE: IEEE 802.3af, Class 3, max. 7 W

Material Plastic

Dimension Ø 121.5 mm × 97.6 mm (Ø 4.78" × 3.84")

Package Dimension 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")

Weight Approx. 600 g (1.2 lb.)

With Package Weight Approx. 790 g (1.7 lb.)

Storage Conditions -10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)

Startup and Operating

Conditions -10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)

Language English, Ukrainian

General Function Heartbeat, anti-banding, mirror, password protection, password reset via email

Approval

EMC

CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC

61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

KC: KN32: 2015, KN35: 2015

Safety

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

Environment

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
