Specification

Camera

Image Sensor 1/3″ Progressive Scan CMOS

Max. Resolution 2560 × 1440

Min. Illumination Color: 0.01 Lux @(F1.2，AGC ON), B/W: 0 Lux with light

Lens

Focal Length 2.8 mm, 4 mm

FOV 2.8 mm, horizontal FOV 104.9°, vertical FOV 58.3°, diagonal FOV 123.3°

4 mm, horizontal FOV 81.3°, vertical FOV 43.7°, diagonal FOV 96.9°

Aperture F1.6

Illuminator

Supplement Light Type IR & White Light

Supplement Light Range White Light Distance: up to 30 m

IR Distance: up to 30 m

Smart Supplement Light Yes

IR Wavelength 850 nm

PTZ

Movement Range (Pan) 0° to 345°

Movement Range (Tilt) 0° to 80°

Pan Speed Pan speed: configurable from 4° to 25°/s

Tilt Speed Tilt speed: configurable from 4° to 20°/s

Video

Video Compression H.265, H.264, MJPEG

H.264 Type Baseline Profile, Main Profile, High Profile

H.265 Type Main Profile

Main Stream 50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360）

60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)

Video Bit Rate 32 Kbps to 8 Mbps

Audio

Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM

Audio Bit Rate 16 Kbps (G.722.1)/64 Kbps (G.711)/32 to 192 Kbps (MP2L2)/16 Kbps (G.726)/16 to 64

Kbps (AAC-LC)/8 to 48 Kbps (PCM)

Audio Sampling Rate 8 kHz/16 kHz

Environment Noise Filtering Yes

Network

Protocols IPv4/IPv6, HTTP, HTTPS, Qos, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, Bonjour

API ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP

Imágen

Image Settings Saturation, brightness, contrast, and sharpness adjustable by client software or web

browser

Wide Dynamic Range (WDR) Digital WDR

Image Enhancement BLC, HLC, 3D DNR

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-board Storage Built-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB

Built-in Microphone 1 built-in microphone

Built-in Speaker 1 built-in speaker

Reset Yes

Evento

Basic Event Motion detection (support alarm triggering by specified target type (human)), video

tampering alarm, exception

Alarm Linkage Upload to FTP/memory card, notify surveillance center, send email, trigger capture,

audible warning, auto-tracking lite

General

Operating Condition -10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing)

General Function Mirror, password protection, watermark

Power

12 VDC ± 25%, 0.75 A, max. 9 W, Ø 5.5 mm coaxial power plug, reverse polarity

protection,

PoE: IEEE 802.3af, 36 V to 57 V, 0.2 A to 0.3 A, max. 10.5 W

Dimensions Camera dimension: 163.9 mm × 185.8 mm × 131.9 mm (6.45" × 7.31" × 5.19")

With package dimensi on: 224 mm × 164 mm × 230 mm (8.82" × 6.46" × 9.06")

Weight Camera weight: 600 g (1.32 lb.)

With package weight: 900 g (2.0 lb.)

Approval

EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN

50130-4: 2011 + A1: 2014)

Protection IP66
